Model No. 15743001
Offering our customers the highest quality at all times is a fundamental part of the Hansgrohe company philosophy.
Planning data
BIM data
Technical data
An EPD is an Environmental Product Declaration. It is like an environmental identity card for products based on the results of a Life Cycle Assessment.
Environmental Product Declaration| Item No. | DescriptionModel No. |
|---|
| a | Grease90920000 |
| f | symbol tub93577880 |
| e | symbol Mono93576880 |
| h | symbol ON/OFF93579880 |
| b | symbol head shower Rain large93571880 |
| c | symbol Flood jet93574880 |
| g | symbol body shower93578880 |
| d | symbol Whirl93575880 |
| i | pushbutton93955880 |
| 1 | non return valve97980000 |
| 2 | noise reduction94073000 |
| 3 | O-ring 16x298133000 |
| 4 | set of screws96525000 |
| 5 | O-ring 36x298156000 |
| 6 | shut off unit95758000 |
| 7 | nut98368000 |
| 8 | Select-adapter92219000 |
| 9 | set of symbols92218000 |
| 10 | thermostat cartridge98282000 |
| 11 | O-ring 20x1,598197000 |
| 12 | O-ring 25x1,598146000 |
| 13 | O-ring 25x2,592146000 |
| 14 | nut98913000 |
| 15 | sleeve92216000 |
| 16 | handle fixing set95843000 |
| 17 | holder for escutcheon98793000 |
| 18 | set of fixing screws96454000 |
| 19 | escutcheon Ø 150 mm92325001 |
| 20 | O-ring 44x498471000 |
| 21 | handle for thermostat92215001 |
| 22 | fit-up aid92540000 |
| 23 | compensation set 1°95521000 |
| 24 | extension 22 mm (Ø 150 mm)13597000 |
| 25 | extension 25 mm13595000 |
| 26 | symbol handshower93573880 |
| 27 | symbol head shower Rain small93572880 |
| 28 | non return valve (pressure-resistant up to 2 MPa)92594000 |
| 29 | nut and flange92696000 |
